| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMBJ75A | SMBJ75CA | NR | DR | 75.0 | 83.30 | 92.10 | 1 | 121.0 | 5.0 | 1.0 | |
| SMBJ78A | SMBJ78CA | NT | DT | 78.0 | 86.70 | 95.80 | 126.0 | 4.8 | |||
| SMBJ85A | SMBJ85CA | NV | DV | 85.0 | 94.40 | 104.00 | 137.0 | 4.4 | |||
| SMBJ90A | SMBJ90CA | NX | DX | 90.0 | 100.00 | 111.00 | 146.0 | 4.1 | |||
| SMBJ100A | SMBJ100CA | NZ | DZ | 100.0 | 111.00 | 123.00 | 162.0 | 3.7 | |||
| SMBJ110A | SMBJ110CA | PE | EE | 110.0 | 122.00 | 135.00 | 177.0 | 3.4 | |||
| SMBJ120A | SMBJ120CA | PG | EG | 120.0 | 133.00 | 147.00 | 193.0 | 3.1 | |||
| SMBJ130A | SMBJ130CA | PK | EK | 130.0 | 144.00 | 159.00 | 209.0 | 2.9 | |||
| SMBJ150A | SMBJ150CA | PM | EM | 150.0 | 167.00 | 185.00 | 243.0 | 2.5 | |||
| SMBJ160A | SMBJ160CA | PP | EP | 160.0 | 178.00 | 197.00 | 259.0 | 2.3 | |||
| SMBJ170A | SMBJ170CA | PR | ER | 170.0 | 189.00 | 209.00 | 275.0 | 2.2 | |||
| SMBJ180A | SMBJ180CA | PT | ET | 180.0 | 201.00 | 222.00 | 292.0 | 2.1 | |||
| SMBJ200A | SMBJ200CA | PV | EV | 200.0 | 224.00 | 247.00 | 324.0 | 1.9 | |||
| SMBJ220A | SMBJ220CA | PX | EX | 220.0 | 246.00 | 272.00 | 356.0 | 1.7 | |||
| SMBJ250A | SMBJ250CA | PZ | EZ | 250.0 | 279.00 | 309.00 | 405.0 | 1.5 | |||
| SMBJ300A | SMBJ300CA | QE | FE | 300.0 | 335.00 | 371.00 | 486.0 | 1.3 | |||
| SMBJ350A | SMBJ350CA | QG | FG | 350.0 | 391.00 | 432.00 | 567.0 | 1.1 | |||
| SMBJ400A | SMBJ400CA | QK | FK | 400.0 | 447.00 | 494.00 | 648.0 | 0.9 | |||
| SMBJ440A | SMBJ440CA | QM | FM | 440.0 | 492.00 | 543.00 | 713.0 | 0.9 | |||
| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMBJ75A | SMBJ75CA | NR | DR | 75.0 | 83.30 | 92.10 | 1 | 121.0 | 5.0 | 1.0 | |
| SMBJ78A | SMBJ78CA | NT | DT | 78.0 | 86.70 | 95.80 | 126.0 | 4.8 | |||
| SMBJ85A | SMBJ85CA | NV | DV | 85.0 | 94.40 | 104.00 | 137.0 | 4.4 | |||
| SMBJ90A | SMBJ90CA | NX | DX | 90.0 | 100.00 | 111.00 | 146.0 | 4.1 | |||
| SMBJ100A | SMBJ100CA | NZ | DZ | 100.0 | 111.00 | 123.00 | 162.0 | 3.7 | |||
| SMBJ110A | SMBJ110CA | PE | EE | 110.0 | 122.00 | 135.00 | 177.0 | 3.4 | |||
| SMBJ120A | SMBJ120CA | PG | EG | 120.0 | 133.00 | 147.00 | 193.0 | 3.1 | |||
| SMBJ130A | SMBJ130CA | PK | EK | 130.0 | 144.00 | 159.00 | 209.0 | 2.9 | |||
| SMBJ150A | SMBJ150CA | PM | EM | 150.0 | 167.00 | 185.00 | 243.0 | 2.5 | |||
| SMBJ160A | SMBJ160CA | PP | EP | 160.0 | 178.00 | 197.00 | 259.0 | 2.3 | |||
| SMBJ170A | SMBJ170CA | PR | ER | 170.0 | 189.00 | 209.00 | 275.0 | 2.2 | |||
| SMBJ180A | SMBJ180CA | PT | ET | 180.0 | 201.00 | 222.00 | 292.0 | 2.1 | |||
| SMBJ200A | SMBJ200CA | PV | EV | 200.0 | 224.00 | 247.00 | 324.0 | 1.9 | |||
| SMBJ220A | SMBJ220CA | PX | EX | 220.0 | 246.00 | 272.00 | 356.0 | 1.7 | |||
| SMBJ250A | SMBJ250CA | PZ | EZ | 250.0 | 279.00 | 309.00 | 405.0 | 1.5 | |||
| SMBJ300A | SMBJ300CA | QE | FE | 300.0 | 335.00 | 371.00 | 486.0 | 1.3 | |||
| SMBJ350A | SMBJ350CA | QG | FG | 350.0 | 391.00 | 432.00 | 567.0 | 1.1 | |||
| SMBJ400A | SMBJ400CA | QK | FK | 400.0 | 447.00 | 494.00 | 648.0 | 0.9 | |||
| SMBJ440A | SMBJ440CA | QM | FM | 440.0 | 492.00 | 543.00 | 713.0 | 0.9 | |||
