| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMAJ75A | SMAJ75CA | RR | ZR | 75.0 | 83.30 | 92.10 | 1 | 121.0 | 3.3 | 1 | |
| SMAJ78A | SMAJ78CA | RT | ZT | 78.0 | 86.70 | 95.80 | 126.0 | 3.2 | |||
| SMAJ85A | SMAJ85CA | RV | ZV | 85.0 | 94.40 | 104.00 | 137.0 | 2.9 | |||
| SMAJ90A | SMAJ90CA | RX | ZX | 90.0 | 100.00 | 111.00 | 146.0 | 2.7 | |||
| SMAJ100A | SMAJ100CA | RZ | ZZ | 100.0 | 111.00 | 123.00 | 162.0 | 2.5 | |||
| SMAJ110A | SMAJ110CA | SE | VE | 110.0 | 122.00 | 135.00 | 177.0 | 2.3 | |||
| SMAJ120A | SMAJ120CA | SG | VG | 120.0 | 133.00 | 147.00 | 193.0 | 2.1 | |||
| SMAJ130A | SMAJ130CA | SK | VK | 130.0 | 144.00 | 159.00 | 209.0 | 1.9 | |||
| SMAJ150A | SMAJ150CA | SM | VM | 150.0 | 167.00 | 185.00 | 243.0 | 1.6 | |||
| SMAJ160A | SMAJ160CA | SP | VP | 160.0 | 178.00 | 197.00 | 259.0 | 1.5 | |||
| SMAJ170A | SMAJ170CA | SR | VR | 170.0 | 189.00 | 209.00 | 275.0 | 1.5 | |||
| SMAJ180A | SMAJ180CA | ST | VT | 180.0 | 201.00 | 222.00 | 292.0 | 1.4 | |||
| SMAJ200A | SMAJ200CA | SV | VV | 200.0 | 224.00 | 247.00 | 324.0 | 1.2 | |||
| SMAJ220A | SMAJ220CA | SX | VX | 220.0 | 246.00 | 272.00 | 356.0 | 1.1 | |||
| SMAJ250A | SMAJ250CA | SZ | VZ | 250.0 | 279.00 | 309.00 | 405.0 | 1.0 | |||
| SMAJ300A | SMAJ300CA | TE | UE | 300.0 | 335.00 | 371.00 | 486.0 | 0.8 | |||
| SMAJ350A | SMAJ350CA | TG | UG | 350.0 | 391.00 | 432.00 | 567.0 | 0.7 | |||
| SMAJ400A | SMAJ400CA | TK | UK | 400.0 | 447.00 | 494.00 | 648.0 | 0.6 | |||
| SMAJ440A | SMAJ440CA | TM | UM | 440.0 | 492.00 | 543.00 | 713.0 | 0.6 | |||
| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMAJ75A | SMAJ75CA | RR | ZR | 75.0 | 83.30 | 92.10 | 1 | 121.0 | 3.3 | 1 | |
| SMAJ78A | SMAJ78CA | RT | ZT | 78.0 | 86.70 | 95.80 | 126.0 | 3.2 | |||
| SMAJ85A | SMAJ85CA | RV | ZV | 85.0 | 94.40 | 104.00 | 137.0 | 2.9 | |||
| SMAJ90A | SMAJ90CA | RX | ZX | 90.0 | 100.00 | 111.00 | 146.0 | 2.7 | |||
| SMAJ100A | SMAJ100CA | RZ | ZZ | 100.0 | 111.00 | 123.00 | 162.0 | 2.5 | |||
| SMAJ110A | SMAJ110CA | SE | VE | 110.0 | 122.00 | 135.00 | 177.0 | 2.3 | |||
| SMAJ120A | SMAJ120CA | SG | VG | 120.0 | 133.00 | 147.00 | 193.0 | 2.1 | |||
| SMAJ130A | SMAJ130CA | SK | VK | 130.0 | 144.00 | 159.00 | 209.0 | 1.9 | |||
| SMAJ150A | SMAJ150CA | SM | VM | 150.0 | 167.00 | 185.00 | 243.0 | 1.6 | |||
| SMAJ160A | SMAJ160CA | SP | VP | 160.0 | 178.00 | 197.00 | 259.0 | 1.5 | |||
| SMAJ170A | SMAJ170CA | SR | VR | 170.0 | 189.00 | 209.00 | 275.0 | 1.5 | |||
| SMAJ180A | SMAJ180CA | ST | VT | 180.0 | 201.00 | 222.00 | 292.0 | 1.4 | |||
| SMAJ200A | SMAJ200CA | SV | VV | 200.0 | 224.00 | 247.00 | 324.0 | 1.2 | |||
| SMAJ220A | SMAJ220CA | SX | VX | 220.0 | 246.00 | 272.00 | 356.0 | 1.1 | |||
| SMAJ250A | SMAJ250CA | SZ | VZ | 250.0 | 279.00 | 309.00 | 405.0 | 1.0 | |||
| SMAJ300A | SMAJ300CA | TE | UE | 300.0 | 335.00 | 371.00 | 486.0 | 0.8 | |||
| SMAJ350A | SMAJ350CA | TG | UG | 350.0 | 391.00 | 432.00 | 567.0 | 0.7 | |||
| SMAJ400A | SMAJ400CA | TK | UK | 400.0 | 447.00 | 494.00 | 648.0 | 0.6 | |||
| SMAJ440A | SMAJ440CA | TM | UM | 440.0 | 492.00 | 543.00 | 713.0 | 0.6 | |||
