| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMA6J51A | SMA6J51CA | MZ | WZ | 51.0 | 56.70 | 62.70 | 1 | 82.4 | 7.3 | 1.0 | |
| SMA6J54A | SMA6J54CA | NE | XE | 54.0 | 60.00 | 66.30 | 87.1 | 6.9 | |||
| SMA6J58A | SMA6J58CA | NG | XG | 58.0 | 64.40 | 71.20 | 93.6 | 6.5 | |||
| SMA6J60A | SMA6J60CA | NK | XK | 60.0 | 66.70 | 73.70 | 96.8 | 6.2 | |||
| SMA6J64A | SMA6J64CA | NM | XM | 64.0 | 71.10 | 78.60 | 103.0 | 5.9 | |||
| SMA6J70A | SMA6J70CA | NP | XP | 70.0 | 77.80 | 86.00 | 113.0 | 5.3 | |||
| SMA6J75A | SMA6J75CA | NR | XR | 75.0 | 83.30 | 92.10 | 121.0 | 5.0 | |||
| SMA6J78A | SMA6J78CA | NT | XT | 78.0 | 86.70 | 95.80 | 126.0 | 4.8 | |||
| SMA6J85A | SMA6J85CA | NV | XV | 85.0 | 94.40 | 104.00 | 137.0 | 4.4 | |||
| SMA6J90A | SMA6J90CA | PE | YE | 90.0 | 100.00 | 111.00 | 146.0 | 4.1 | |||
| SMA6J100A | - | PG | - | 100.0 | 111.00 | 123.00 | 162.0 | 3.7 | |||
| SMA6J110A | - | PK | - | 110.0 | 122.00 | 135.00 | 177.0 | 3.4 | |||
| SMA6J120A | - | PM | - | 120.0 | 133.00 | 147.00 | 193.0 | 3.1 | |||
| SMA6J130A | - | PP | - | 130.0 | 144.00 | 159.00 | 209.0 | 2.9 | |||
| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMA6J51A | SMA6J51CA | MZ | WZ | 51.0 | 56.70 | 62.70 | 1 | 82.4 | 7.3 | 1.0 | |
| SMA6J54A | SMA6J54CA | NE | XE | 54.0 | 60.00 | 66.30 | 87.1 | 6.9 | |||
| SMA6J58A | SMA6J58CA | NG | XG | 58.0 | 64.40 | 71.20 | 93.6 | 6.5 | |||
| SMA6J60A | SMA6J60CA | NK | XK | 60.0 | 66.70 | 73.70 | 96.8 | 6.2 | |||
| SMA6J64A | SMA6J64CA | NM | XM | 64.0 | 71.10 | 78.60 | 103.0 | 5.9 | |||
| SMA6J70A | SMA6J70CA | NP | XP | 70.0 | 77.80 | 86.00 | 113.0 | 5.3 | |||
| SMA6J75A | SMA6J75CA | NR | XR | 75.0 | 83.30 | 92.10 | 121.0 | 5.0 | |||
| SMA6J78A | SMA6J78CA | NT | XT | 78.0 | 86.70 | 95.80 | 126.0 | 4.8 | |||
| SMA6J85A | SMA6J85CA | NV | XV | 85.0 | 94.40 | 104.00 | 137.0 | 4.4 | |||
| SMA6J90A | SMA6J90CA | PE | YE | 90.0 | 100.00 | 111.00 | 146.0 | 4.1 | |||
| SMA6J100A | - | PG | - | 100.0 | 111.00 | 123.00 | 162.0 | 3.7 | |||
| SMA6J110A | - | PK | - | 110.0 | 122.00 | 135.00 | 177.0 | 3.4 | |||
| SMA6J120A | - | PM | - | 120.0 | 133.00 | 147.00 | 193.0 | 3.1 | |||
| SMA6J130A | - | PP | - | 130.0 | 144.00 | 159.00 | 209.0 | 2.9 | |||
