| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMA6J5.0A | SMA6J5.0CA | KE | TE | 5.0 | 6.40 | 7.00 | 10 | 9.2 | 65.3 | 800 | |
| SMA6J6.0A | SMA6J6.0CA | KG | TG | 6.0 | 6.67 | 7.37 | 10.3 | 58.3 | 800 | ||
| SMA6J6.5A | SMA6J6.5CA | KK | TK | 6.5 | 7.22 | 7.98 | 11.2 | 53.6 | 500 | ||
| SMA6J7.0A | SMA6J7.0CA | KM | TM | 7.0 | 7.78 | 8.60 | 12.0 | 50.0 | 200 | ||
| SMA6J7.5A | SMA6J7.5CA | KP | TP | 7.5 | 8.33 | 9.21 | 1 | 12.9 | 46.6 | 100 | |
| SMA6J8.0A | SMA6J8.0CA | KR | TR | 8.0 | 8.89 | 9.83 | 13.6 | 44.2 | 50 | ||
| SMA6J8.5A | SMA6J8.5CA | KT | TT | 8.5 | 9.44 | 10.40 | 14.4 | 41.7 | 20 | ||
| SMA6J9.0A | SMA6J9.0CA | KV | TV | 9.0 | 10.00 | 11.10 | 15.4 | 39.0 | 10 | ||
| SMA6J10A | SMA6J10CA | KX | TX | 10.0 | 11.10 | 12.30 | 17.0 | 35.3 | 5 | ||
| SMA6J11A | SMA6J11CA | KZ | TZ | 11.0 | 12.20 | 13.50 | 18.2 | 33.0 | 1 | ||
| SMA6J12A | SMA6J12CA | LE | UE | 12.0 | 13.30 | 14.70 | 19.9 | 30.2 | |||
| SMA6J13A | SMA6J13CA | LG | UG | 13.0 | 14.40 | 15.90 | 21.5 | 28.0 | |||
| SMA6J14A | SMA6J14CA | LK | UK | 14.0 | 15.60 | 17.20 | 23.2 | 25.9 | |||
| SMA6J15A | SMA6J15CA | LM | UM | 15.0 | 16.70 | 18.50 | 24.4 | 24.6 | |||
| Part Number |
Device Marking Code |
Reverse Stand-Off Voltage VRWM(V) |
Breakdown Voltage VBR(V) @IT |
Test Current IT (mA) |
Maximum Clamping Voltage VC(V)@IPP |
Maximum Peak Pulse Current IPP (A) |
Maximum Reverse Leakage IR@ VRWM (μA) |
||||
| Uni-Polar | Bi-Polar | Uni | Bi | Min | Max | ||||||
| SMA6J5.0A | SMA6J5.0CA | KE | TE | 5.0 | 6.40 | 7.00 | 10 | 9.2 | 65.3 | 800 | |
| SMA6J6.0A | SMA6J6.0CA | KG | TG | 6.0 | 6.67 | 7.37 | 10.3 | 58.3 | 800 | ||
| SMA6J6.5A | SMA6J6.5CA | KK | TK | 6.5 | 7.22 | 7.98 | 11.2 | 53.6 | 500 | ||
| SMA6J7.0A | SMA6J7.0CA | KM | TM | 7.0 | 7.78 | 8.60 | 12.0 | 50.0 | 200 | ||
| SMA6J7.5A | SMA6J7.5CA | KP | TP | 7.5 | 8.33 | 9.21 | 1 | 12.9 | 46.6 | 100 | |
| SMA6J8.0A | SMA6J8.0CA | KR | TR | 8.0 | 8.89 | 9.83 | 13.6 | 44.2 | 50 | ||
| SMA6J8.5A | SMA6J8.5CA | KT | TT | 8.5 | 9.44 | 10.40 | 14.4 | 41.7 | 20 | ||
| SMA6J9.0A | SMA6J9.0CA | KV | TV | 9.0 | 10.00 | 11.10 | 15.4 | 39.0 | 10 | ||
| SMA6J10A | SMA6J10CA | KX | TX | 10.0 | 11.10 | 12.30 | 17.0 | 35.3 | 5 | ||
| SMA6J11A | SMA6J11CA | KZ | TZ | 11.0 | 12.20 | 13.50 | 18.2 | 33.0 | 1 | ||
| SMA6J12A | SMA6J12CA | LE | UE | 12.0 | 13.30 | 14.70 | 19.9 | 30.2 | |||
| SMA6J13A | SMA6J13CA | LG | UG | 13.0 | 14.40 | 15.90 | 21.5 | 28.0 | |||
| SMA6J14A | SMA6J14CA | LK | UK | 14.0 | 15.60 | 17.20 | 23.2 | 25.9 | |||
| SMA6J15A | SMA6J15CA | LM | UM | 15.0 | 16.70 | 18.50 | 24.4 | 24.6 | |||
